Card reader, compatible with access controls and attendance
  • Card reader, compatible with access controls and attendance - Image 1
  • Card reader, compatible with access controls and attendance - Image 2
  • Card reader, compatible with access controls and attendance - Image 3
  • Card reader, compatible with access controls and attendance - Image 4
  • Card reader, compatible with access controls and attendance - Image 5
  • - Elegant casing design.
  • - Simple and convenient operation method.
  • - Standard ID card.
  • - Full door lock control system.
  • - Wiegand out to connect with control panel.
  • - Easy to install.
  • This access control device has an elegant design and a professional surface treatment. Also, it features a lock control, alarm, exit button and door sensor.

    Its Wiegand-in interface is used to connect external readers to construct master and slave system. Likewise, it can be used to connect with a control panel as a reader by Wiegand-out interface.

    This operation can be done with PC software and uploaded to the device through TCP/IP, RS232/485 communication. The USB-host is used for data download and upload, including user data and record, etc. This device is perfect to be used at a house, a small office or a factory, etc.

    Main features:
    - Elegant case design.
    - Easy to install, safe and reliable.
    - Simple and convenient operation method.
    - Standard ID card, Mifare card optional.
    - Full door lock control system.
    - Wiegand out to connect with control panel.
    - Wiegand in to construct master and slave system.
    - Audio prompt and LED feedback guide the user to operate.

    Warranty: One (1) Year
  • Card reader, compatible with access controls and attendance
    General
    Brand LineMak
    Model LB-SCR100
    Biometric control
    Language Spanish
    Communication TCP/IP, RS232/485, USB-Host
    Applications Mifare, HID
    Capacity ID Card: 30000
    Transaction: 50000
    Wiegand signal Output and Input
    Functions Anti-passback, Webserver, 9 digital number.
    Access control interface 3rd party electric lock, door sensor, exit button, alarm, Door Bell
    Environment
    Operation temperature 0ºC ~ 45ºC / 32ºF ~ 113ºF
    Working humidity 20% - 80%
    Power
    Power supply DC 12V
    Appearance
    Color Black
    Size 1.19(L) * 6.11(H) * 3.94(W) inches
    Weight 11.82 ounces
