Vandalproof PTZ Camera, SONY CCD Sensor, 650TVL, 393~492ft IR
  • Vandalproof PTZ Camera, SONY CCD Sensor, 650TVL, 393~492ft IR - Image 1
  • - Patent of video analysis light-adjustment technology.
  • - Modular circuit design.
  • - Weatherproof: IP66.
  • - RTC clock for timing function.
  • - Intelligent video analysis.
  • - The dome program can be upgraded online remotely.
  • Metal vandalproof PTZ camera. High image quality and resolution, with different settings for surveillance and remote monitoring with an average speed of PAN / TIL / ZOOM lens and auto focus, night vision of 393-492ft. Available in white.

    Top of the line equipment regarding sensor and driver technology.

    This equipment, designed for outdoors, can be easily installed. Its resolution, sensitivity and wide opening angle are perfect for monitoring stores, offices, shops, warehouses and anywhere with little or no lighting.

    For best results, regarding image quality, use our servers and digital video recorders (DVR). See this camera online through any of our recording systems.

    Weatherproof: IP66

    Main features:
    - 393~492ft IR distance.
    - First patent of video analysis light-adjustment technology. Incredible night vision effect, saving 50% power consumption and increases the IR LED´s longevity.
    - First built-in heat sinking water and dust proof with high reliability.
    - Auto-tracking function with zoom in/out for unmanned surveillance.
    - Wipers equipped to ensure a clear and crispy video image.
    - 5 inch alloy aluminum construction design for housing. Equipped with side-open power box integrated wall bracket.
    - Modular circuit design, support of self-testing of the core module.
    - Powerful infrared LEDs control software suitable for more occasions.
    - Intelligent video analysis capabilities to detect the designated area.
    - Built-in precision RTC clock for timing function.
    - The dome program can be upgraded online remotely.
    - Patent of suspended quick installation design.

    Power adapter included.

    Cover what's in front of you with Pan-Tilt
    Cover what's in front of you with Pan-Tilt
    With pan-tilt feature (panning referring to horizontal movement of the lens and tilting to vertical movement), you can control the movement of the camera from a remote location by using controls on an Internet browser or software application. Cover large areas when used for security monitoring or recording without any user input, especially overnight.
    IR illumination gives your cameras night vision
    IR illumination provides an extra source of invisible infrared light for surveillance when existing ambient light is either not present or too dim. And it is designed to be easily integrated into the IP network surveillance system and powered by PoE.
    IR illumination gives your cameras night vision
    Weatherproof cameras in a year-round protection
    Weatherproof cameras in a year-round protection
    Our outdoor weatherproof cameras feature at least an IP66 weather rating. These outdoor cameras are built to keep out small particles such as dust and water, and are unaffected by a range of weather conditions including heavy rain and snow.
    Warranty: One (1) Year
  • Vandalproof PTZ Camera, SONY CCD Sensor, 650TVL, 393~492ft IR
    General
    Brand LineMak
    Model LS-HSP646-C27G
    Sensor
    Resolution 650TVL
    Sensor 1/3" SONY Super HAD II CCD
    Effective pixels PAL: 976*582
    NTSC: 976*494
    Video
    Video format PAL / NTSC
    Video output 1.0/0.2Vp-p, 75ohm, BNC connector
    Network
    On-line update Update via communication bus for the dome program
    Lens
    Lens 3.9mm~105.6mm
    IR Range 393ft ~ 492ft
    LEDs 9pcs
    Zoom Optical: 27x
    Viewing angle 1° ~ 90°
    Security
    Motion detection zone 8 zones with settable title
    Privacy zone 8 with settable title
    PTZ
    Communication protocol Self-recognition, Pelco-D/P, HS etc.
    Preset 256 with defined titles
    Patrol track 4 groups, each one with 500 instructions or 30 min operation
    Pattern tracking record 8 groups, each one with 32 presets with settable time interval
    Auto-scan 8 groups, settable boundaries and scan speed
    Pan & Tilt speed Pan: 0.01~360º/S
    Tilt: 0.01~120º/S
    Rotation range Pan: 360° continuous rotation
    Tilt: -5°~90° auto flip
    Guarding position Call upon preset, auto scan, cruise or pattern tours after no operation
    Accuracy rating of preset 0.1°
    3D Positioning Pan/tilt. and zoom in/out via software interface
    Environment
    Operation temperature -35°C ~ 55°C
    -31ºF ~ 131ºF
    Weatherproof standard IP66 (protection against dust and strong water pressure)
    Working humidity <90% (No Condensing)
    Power
    Power consumption 50W (Day 16W, Night lamp start 40W)
    Working voltage DC 12V
    Lightning protection Level 2, 3000V surging prevention
    Appearance
    Color White
    Size 12.21 (L) 13.36 (H) 9.85 (W) inches
    Weight 8.51 pounds
    Material Metal
    Accessories
    Wipers Yes
    Standard
    Response time RTC clock design for timing events during the whole week
    S/N Ratio >48dB
  • Instructions
    File Size: 318.24Kb
    Languages: English
    File Type: PDF
